Door Seals

DESCRIPTION

The door seals create a foam-filled compression around a trailer’s top and sides, supporting energy efficiency and climate control. Save money in reduced energy costs and increase productivity by enabling a safe and comfortable working environment. Available with head pads or head curtains and a wide range of fabric types.

MODELS

FIXED HEAD PAD
8’0”W X 8’0”H OPENINGS
This unit is recommended when the tightest possible seal is required and full access to the rear of the truck is not required.
Two foam side pads and one foam head pad wrap around the door opening, sealing the gap between the building wall and the truck.

ADJUSTABLE HEAD CURTAIN
8’0”W X 10’0”H OPENINGS
This unit is used to seal higher door openings when a head pad will not work.
A top header curtain is supplied with a rope & pulley system that can be raised and lowered to suit a variety of truck
heights.
Two foam side pads seal the gap between the building wall and the truck.

ADJUSTABLE HEAD PAD
8’0”W X 10”0H OPENINGS
This unit is used on higher door openings when a variety of trailer heights are being serviced.
Two foam side pads seal the gap between the building wall and the truck while a foam head pad that can be raised and lowered on a track and roller system creates a tight seal at the top of the truck.
A torsion spring with an integral follower curtain ensures a complete seal.

ADJUSTABLE HEAD CURTAIN FULL

ACCESS SEAL
10’0”W X 10’0”H OPENINGS
This unit is ideal when full access to the rear of the truck is required. With a standard velcro split head curtain, this unit services a variety of truck heights. Unlike conventional pads that seal the back of the truck, this unit allows the truck to back through the vertical pads forming a tight seal against the sides of the truck.
The velcro split head curtain is raised and lowered on top of the truck allowing full access to the rear of the truck.

FIXED HEAD PAD FULL ACCESS SEAL
10’0”W X 8’0”H OPENINGS
This unit is recommended for wider door openings when conventional side pads won’t work.
This unit combines full access on the sides of the trailer while a compressible top pad that creates a tight seal above the door opening.

FIXED INFLATABLE
8’0”W X 8’0”H OPENINGS
The Series D150 reduces pressure against the building wall unlike conventional pads while creating a tight energy saving seal against the back of the truck.
A one-piece airbag construction with a unique internal baffle system creates a square-faced design increasing contact area.
This design ensures that off-centre trailers & even trailers that are not spotted square to the opening are sealed.
